Components



1

Forged and machined brass body for thermostatic radiator valve Rif. 730



2

Forged and machined brass body for solenoid valve with sweat ends Rif. 284



3

Forged and machined brass body for solenoid valve with flare ends Rif. 290



4

Forged and machined brass body for solenoid valve with threaded ends and filter Rif. 351



5

Forged and machined brass elbow Rif. 105A



6

Forged and machined brass elbow Rif. 540



7

Cast and machined brass elbow Rif. 947



8

Forged and machined brass elbow Rif. 715



9

Forged and machined sweat by thread brass fitting with connection for thermal sensor Rif. 294



10

Forged and machined sweat by threaded union end brass fitting with vent Rif. 500



11

Forged and machined brass T type fitting with union end Rif. 013



12

Forged and machined brass distribution fitting for gas Rif. 464



13

Forged and machined brass distribution fitting for gas Rif. 467



14

Forged and machined brass distribution fitting Rif. 062



15

Forged and machined brass distribution fitting with connection for thermal sensor Rif. 740



16

Forged and machined brass distribution fitting with connection for thermal sensor Rif. 119



17

Forged and machined brass distribution fitting Rif. 593



18

Ball with integrated safety functions machined from brass bar stock Rif. PS1G25



19

Forged and machined brass distribution fitting Rif. O11-111



Special valves



20

Forged brass ball valve with pump connection and by-pass Rif. 618D



21

Forged brass ball valve with union end and flat gasket seat Rif. 215GSP



22

Forged brass angle valve with union end and flat gasket seat Rif. 412GSSP



23

Forged brass angle valve with shut-off and system filling/drainage functions Rif. 919



24

Forged brass angle ball valves with following functions:

  • shut-off
  • filling and drainage of system
  • manifold

Rif. 911



25

Forged low lead brass ball valve with integrated rotary flange for connection to pump and non-return check valve Rif. R243



26

Forged brass ball valve with quick disconnect connections and mounting holes for automotive filter applications Rif. O11-080



27

3-way forged brass ball valve with quick disconnect / threaded connection and mounting plate Rif. 011-043

Integrated solutions and assembly kits

Steel plate with ready-to-be-connected valves

28



Integration of various components into a single product

Original situation

29

  1. Components bought through various vendors
  2. Standard RuB shut-off ball valves
  3. Assemblies and testing at customer’s site



Solution developed together with customer

30

valve bodies were eliminated and valve components were integrated into aluminum manifold



Final product

31

ADVANTAGES
More compact and lighter
Lower assembly costs
Lower maintenance costs
Considerably fewer leak paths
Considerably higher safety and reliability
Interaction with one vendor only



Additional configurations developed through time

32



Integration of various components into a single product

Original situation

33



Final product

34
