• 24h 100% seal test guaranteed
• Dual sealing system allows valve to be operated in either direction making installation easier
• No metal-to-metal moving parts
• No maintenance ever required
• Handle clearly shows ball position
• Silicone-free lubricant on all seals
• Handle stops on body to avoid stress at stem
• Chrome plated brass ball for longer life with rinse hole (the rinse hole is expected from 1/2″ up to 2″ sizes)

• Full port to DIN 3357 for 1/4″ and 3/8″ sizes, nominal port for compact design from 1/2″ to 2″ sizes.

• Geomet® carbon steel handle with thick PVC dip coating. Handle coating offers both thermal and electrical protection
• Handle removable with valve in service
• WARNING: do not exceed reasonable temperature and/or electrical load

• Blowout-proof nickel plated brass stem
• Maintenance- free, double FPM O-rings at the stem for maximum safety

• 40 bar (600 PSI) up to 3/8”, 30 bar (450 PSI) over 3/8” non-shock cold working pressure
• -40°C to +170°C (-40°F to +350°F)
• WARNING: freezing of the fluid in the installation may severely damage the valve

• Pure PTFE self-lubricating seats with flexible-lip design

• EN 10226-1 parallel female by female threads (S.51 model)
• Female by female threads
• Stem extension
• T-handle
• Oval lockable handle
• Stainless steel handle (1.4016 / AISI 430)
• Patented locking device
• Stubby handle
• RuB memory stop designed to be installed with our stubby handle

• ISO 228 parallel male by female threads

• According to 2014/68/UE module A: it cannot be used with dangerous gases in sizes larger than 25mm

• EAC – Declaration of conformity (Russia, Kazakhstan, Belarus)
• RoHS Compliant (EU)

NOTE: approvals apply to specific configurations/sizes only.
