• 24h 100% seal test guaranteed
• Dual sealing system allows valve to be operated in either direction making installation easier
• No metal-to-metal moving parts
• No maintenance ever required
• Handle clearly shows ball position
• Silicone-free lubricant on all seals
• Chrome plated brass ball for longer life
• Handle stops on body to avoid stress at stem

• 100 % full port for maximum flow

• Hot forged sand blasted, nickel plated brass body and cap sealed with Loctite® or equivalent threads sealant
• Finest brass according to EN 12165 and EN 12164 specifications

• Geomet® carbon steel handle with thick PVC dip coating. Handle coating offers both thermal and electrical protection
• WARNING: do not exceed reasonable temperature and/or electrical load

• Blowout-proof nickel plated brass stem
• Pure PTFE adjustable packing gland and reinforced washer for lower torque and easy maintenance

• 65 bar (940 PSI) up to 1″, 40 bar (600 PSI) over 1″ non- shock cold working pressure
• -40°C to +170°C (-40°F to +350°F)
• WARNING: freezing of the fluid in the installation may severely damage the valve

• Pure PTFE self-lubricating seats with flexible-lip design

• T-handle
• Oval lockable handle
• Stainless steel handle (1.4016 / AISI 430)
• Patented locking device

• EN 10226-1, ISO 228 parallel female thread by EN 10226-1 taper male

• Stainless steel ball and/or stem (1.4401 / AISI 316)
• Glass filled PTFE seals
• Custom design

• According to 2014/68/UE module A: it cannot be used with dangerous gases in sizes larger than 25mm

• EAC – Declaration of conformity  (Russia, Kazakhstan, Belarus)
• RoHS Compliant (EU)

  NOTE: approvals apply to specific configurations/sizes only.
